Damping compounds

Name: Damping compounds
SKU: 9173
Availability: InStock

Damping Compound is a tacky, viscous gel that is designed to dampen the free motion of the component to which it is applied. Ordinary lubricants have the property of reducing friction between the mating surfaces, whereas Damping Grease is designed to create more friction and yet make motion smoother and more restricted. This smooth yet restricted or damped motion is free from play and produces a hydraulic/ hand-built feel. The electronics industry utilizes damping greases for potentiometers, rotary switches, tape recorder soft ejection assemblies, variable condensers, deflector coils, trimmers, plastic gears, and other components where damping of free motion is required.

The automobile industry uses damping grease in the production of automobile components, switchgear, mirror assemblies, etc. These greases also provide a smooth and easy motion to oculars, focusing and adjusting on screw and plane contracts.

Other applications include optical equipment, binoculars, radio, telescopes, microscopes, cameras, range finders, surveying and measuring instruments, electronic toys, hinges, builders’ hardware, etc.

Call Now +919810072294

Product successfully added to the Quote List

Category: Grease & Lubricants

Description

Description

Grade	Appearance	Type	Penetration	Drop point °C	Base Oil Viscosity @40°C	Serviceable Temperature °C	Packing
0021S	Translucent white	Syn Fluid	400-430	180	200-300	4 to 60		18kg
0021W	Translucent white	Syn Fluid	72K±12K*	180	200-300	4 to 60		18kg
0022	Translucent white	Syn Fluid	400-475	180	300-500	4 to 60		18kg
0022H	Translucent white	Syn Fluid	400-430	180	300-500	4 to 60		18kg
0023	Translucent brown	Syn Fluid	445-475	180	300-500	4 to 60		18kg

0001	Pale Brown	Syn Fluid	400-430	180	200-300	10-150	1kg
0868	Pale Brown	Syn Fluid	355-385	>120	3500-4500	10-180	0.9kg
9290	Pale Brown	Syn Fluid	175-205	Nil	3500-4500	10-180	1kg
1520	Pale Brown	Syn Fluid	160-190	Nil	3500-4500	10-180	1kg
1521	Pale Brown	Syn Fluid	160-200	Nil	3500-4500	10-180	1kg
1522	Pale Brown	Syn Fluid	160-200	Nil	3500-4500	10-180	1kg
1523	Pale Brown	Syn Fluid	130-160	Nil	3500-4500	10-180	1 kg
7523	Pale Brown	Syn Fluid	130-160	Nil	3500-4500	10-180	23kg
7527	Pale Brown	Syn Fluid	80-110	Nil	> 5000	10-180	22kg
